Type: Electrical Discharge Machining (EDM/Wire EDM) filter element, disc/pleated cartridge

Function: Filters metal shavings, carbon powder, and impurities from EDM oil/working fluid, protecting machine tools and machining accuracy.

 1. Dimensions

- Outer Diameter: 150 mm

- Inner Diameter: 31 mm (33 mm universal version also available)

- Height: 355 mm (approximately 350 mm)

 2. Core Parameters

- Filtration Accuracy: 5 μm (common, 10 μm optional)

- Filter Media: Imported wood pulp fiber/pleated filter paper, inner and outer protective mesh (galvanized/stainless steel)

- Operating Temperature: -5℃ ~ +120℃

- Maximum Pressure Drop: 5–8 bar

- Compatible Fluids: EDM oil, kerosene, synthetic cutting fluid

 3. Model Description

- 05951101201: Original part number (commonly found on Charmilles/Agie wire EDM machines)

- E-05951101201: Domestic replacement universal model

 4. Compatibility and Replacement

- Compatible Models: Charmilles, Agie, Dimon, Hanba, Spark and other wire EDM/EDM machines

- Replacement Cycle: 200–500 hours (depending on machining volume and oil contamination level)

- Common Replacement: 150×33×350mm universal EDM filter element (5μm precision)

 5. Features

- Folded structure, large filtration area, strong dirt holding capacity

- Acid and alkali resistant, corrosion resistant, compatible with various working fluids

- High cost-performance ratio, easy replacement
