PP meltblown filter element made of hot-melt entangled polypropylene microfiber, do not use any chemical adhesives, fiber bonding is formed in the space random from three-dimensional microporous structure, fabric collection surface, deep, coarse filter in one, As the fiber and density form high filtration precision and assimilative capacity in the diameter direction of the filter element, the pressure difference is small, deep filtration structure within the outer sparse density gradient pore size, strong pollutant that can remove suspended solids in the liquid flow effectively, particulates, rust and other impurities, high filtering effect, life is long.
PP meltblown filter element aperture compact and uniform, filtration efficiency is high. Due to particle bridging phenomenon occurs in PP meltblown filter element pores, make less than pore blocking particles can be live, filtration efficiency is above 99%, PP meltblown filter element itself cleanness of water pollution, resist acid , alkali and other chemicals and organic solvents corrosion.
Filtration precision: 0.5μm, 1μm, 3μm, 5μm, 10μm, 20μm, 30μm, 40μm, 50μm, 75μm
filter element Length: 10 ", 20", 30 ", 40", 50 ", 60"
filter element outter diameter: 63mm, 115mm
filter element inner diameter: 28mm
Maximum pressure: 21 ℃, 2.0bar
Highest temperature: 50 ℃
Use for the livelihood of drinking water filter RO reverse osmosis filter
Used for industrial process acid liquid filtration
Filter industrial water, electroplating filter
Imaging liquid,filter ink
Sterile water, ultra pure water pre-filtration treatment
Chemical raw materials, organic solvent filtration
