Product Model  CF33986 (Main Model), V2F (Matching Specification Code)

 Related Model  FRP-95-209 (Matching Coalescing Filter Cartridge)

 Product Type  Natural Gas Coalescing Filter Cartridge / Gas Pipeline Filter Cartridge

 Structure Form  Sintered Filter Cartridge, Pleated Filter Cartridge

 Material  Stainless Steel Mesh, Glass Fiber, Polyester Fiber, Polymer Composite Material

 Technical Parameters

 Filtration Accuracy  Glass Fiber Filter Media: 1-70μm; Filter Paper Filter Media: 5-40μm

 Rated Flow Rate  6~9100 L/min

 Working Pressure  ≤450 kg (approx. 44 MPa)

 Working Temperature  -30~120℃

 Sealing Material  High-Temperature Asbestos Gasket, Fluororubber (FKM)  Filtration Efficiency  ≥99.99% efficiency for ≥0.5μm dust

 Main Application Areas

1. Natural Gas Pipeline Systems: Natural gas purification at gathering stations, compressor stations, distribution stations, pigging stations, and terminal stations.

2. Gas Turbines: Inlet filtration system to protect gas turbine blades.

3. Petrochemical Industry: Particulate filtration of natural gas in oil refining and chemical production processes.

4. Energy Industry: Combustion gas filtration in power plants and steel mills.

5. City Gas: Gas purification in transmission and distribution networks.

6. Industrial Combustion: Gas filtration for boilers, kilns, and other combustion equipment.

 Functional Features

- Falling and Separation: Effectively removes droplets (oil, water, etc.) and solid particles from natural gas.

- Dust and Impurity Removal: Filters contaminants and debris from pipe walls.

- Equipment Protection: Ensures the safe operation of downstream gas equipment (pressure regulators, meters, gas turbines, etc.). Meets stringent standards: Complies with ultra-low emission requirements and is subject to stringent environmental emission standards.
