Parameter

1. Material: HV fiberglass, Ahistrom filter paper, stainless steel wire mesh

2. Filter accuracy: from 1, 3, 6, 12, 25 …um

3. Pressure: 1.0Mpa, 2.0Mpa, 16.0Mpa, 21.0Mpa

4. Application field: hydraulic system, lubrication system

5. O-Ring: NBR, fluororubber

Application

1.Metallurgy: used in hydraulic system of rolling mill, caster filter and various kinds of lubrication of filtering.

2.Petrochemicals: oil refining, chemical production process of products.

3.Textile: polyester melt in the purification and drawing process even filter, air compressor protection filtering.

4.Electronic and pharmaceutical: reverse osmosis water, deionized water to treatment filter and wash the liquid

and glucose former treatment filter.

Test Standard

＊ Our filter elements are tested according to ISO 2943

＊ Compatibility with hydraulic fluids ISO 3968

＊ Flow characteristics ISO/DIS 3724

＊ Flow fatigue characteristics ISO/DIS 4572

＊ Filter performance test (Multi-pass test) ISO 2942

＊ Proof of integrity and quality (Bubble point test) ISO 3723

＊ Verification of the end cap stress ISO 2941

＊ Collapse / burst pressure verification
